HR2-10 brick machine is the cheapest fully automatic hydraulic clay brick making machine
HR2-10 brick machine is a mechanical equipment that can press clay raw materials into bricks. In modern times, international organizations such as the United Nations advocate green environmental protection and sustainable development. According to market demand, HENRY developed a clay brick machine with clay as the main raw material. The finished clay bricks do not need to be fired, but only need to be maintained before use. It is low-carbon and environmentally friendly, with low production costs, so brick machines are very popular in developing countries such as Asia, Africa, and South America.
What are the reasons why HR2-10 brick machine is popular among builders around the world?
First of all, the HR2-10 brick machine can produce not only one type of clay brick, but also another type of clay brick by replacing the mold of the brick making machine. When customers purchase brick cutting machine, they can customize the mold according to several popular local brick types, thus realizing diversified clay brick supply.
HR2-10 brick machine can realize the automatic production of clay bricks through PLC electric control box, reduce the use of workers and reduce labor costs. The electric control box of brick cutter machine can accurately control each production step of clay bricks, so that the production capacity and quality of clay bricks can be greatly improved.
When we designed and produced HR2-10 brick machine, we gave priority to the quality of brick laying machine, and we adopted ultra-high standard production process for HR2-10 brick machine. First of all, the steel material is thickened manganese steel plate, which can ensure that the interlocking brick machine will not have frame deformation, severe wear and tear during the next decades of use, which is very important for ensuring the stability of brick moulding machine in producing clay bricks.
A qualified clay brick is closely related to the hydraulic pressure of the HR2-10 brick machine. We can simply understand that the greater the hydraulic pressure, the greater the pressure on the clay raw materials in the press brick machine mold box, so that the clay bricks produced by the brick press machine are more compact, strong and durable. For this reason, we have increased the hydraulic pressure of the HR2-10 brick machine to 40 tons, which can compress 190mm clay raw materials to 100mm, which determines the quality, firmness and surface smoothness of a clay brick.
The large output is also one of the important advantages of HR2-10 brick machine. HR2-10 clay brick machine can produce two hydraform bricks of 230*220*115mm at a time, and the daily output can reach 4,000 hydraform bricks, with considerable output.
Technical Data
- Tab1
Specification Parameter
| Overall size | 2400*1400*2800mm |
| Shaping cycle | 10-15 seconds |
| Main power | 7.5kw |
| Voltage | 380v/50 hz 3 phase(Adjustable) |
| Production capacity | 700-720 bricks/ per hour |
| Mixer | JQ350 |
| Pressure | 40 tons (adjustable ) |
| Worker | 2-3 Worker |
| Block mould | One set for free |
| Total weight | 1400kgs |
| Color | Customizable |
| Machinery Test Report | Provided |
| Raw material | Clay, cement |
| Place of Origin | Shandong |
| Condition | New |
| After-sales Service Provided | Engineers available to service |
| Product name | HR2-10 brick machine |
HR2-10 brick machine production capacity:
Why choose HR2-10 brick machine? Henry tells you six answers
01.Block mould
The mold of HR2-10 brick machine directly determines the size and shape of the finished bricks, which is of great significance. First of all, the raw material of the mold of brick making machine price is Q345B high-strength steel plate, which is processed by high-precision wire cutting and quenching process on the mold surface. Finally, the anti-rust layer is sprayed on the surface of HR2-10 brick machine, which can ensure that the mold will not rust and has strong wear resistance.
02.PLC electric control box
Every step of HR2-10 brick machine production of clay bricks is inseparable from the PLC electric control box. The electronic components of the PLC electric control box of brick machine price are all imported brands, with standardized internal wiring and clear markings. The program settings and action sequences of the PLC electric control box of HR2-10 brick machine are professionally set by HENRY engineers, which makes the brick making machine for sale production of clay bricks accurate, safe and reliable.
03.Solenoid valve
The solenoid valve can drive the oil cylinder by controlling the flow direction of the hydraulic oil of the HR2-10 brick machine, realizing the hydraulic, molding, demoulding and other actions of the brick machine for sale. The solenoid valve is linked with the PLC electric control box to realize the automatic production of the HR2-10 brick machine. The solenoid valve of the hanje brick machine is selected from high-quality brands, with stable operation and fast response speed, and the response time is less than 0.03 seconds.
04.Electrical motor
The motor provides power for the entire hydraulic system and power system of the HR2-10 brick machine, completing the actions of mixing clay raw materials, transporting clay raw materials, and forming clay bricks. The HR2-10 brick machine is equipped with a 7.5kw motor, which has sufficient power to ensure the implementation of the 40 tons hydraulic force of the revaro brick machine.
05.Hydraulic oil pipe
Hydraulic oil pipes can transmit hydraulic oil and connect HR2-10 brick machine hydraulic system components. Therefore, HENRY uses high-quality hydraulic oil pipes that can withstand high pressure and high temperature. The hydraulic oil pipes of HR2-10 brick machine manual use flange and threaded interfaces, which have good sealing and will not leak or burst.
06. Hydraulic Station
The Hydraulic station is mainly responsible for providing and controlling the hydraulic power of the HR2-10 brick machine, realizing the hydraulic pressure, mold rising and falling steps. The Hydraulic station of the HR2-10 brick machine has a large flow rate, fast oil return speed, smoother automatic operation, and more stable hydraulic pressure, so the clay bricks produced by the HR2-10 brick machine are more compact and stronger.
Advantages of HR2-10 brick machine
Workers use clay bricks to build a house
- Real pictures from the scene
Some clay bricks pictures and parameters (6)
Size:300×150×100mm
2 pieces per mould
480 pieces per hour
3840 pieces per 8 hours
Size:150×150×100mm
4 pieces per mould
960 pieces per hour
7680 pieces per 8 hours
Size:300×150×100mm
2 pieces per mould
480 pieces per hour
3840 pieces per 8 hours
Size:150×150×100mm
4 pieces per mould
960 pieces per hour
7680 pieces per 8 hours
Size:300×150×100mm
2 pieces per mould
480 pieces per hour
3840 pieces per 8 hours
Size:230×220×115mm
2 pieces per mould
480 pieces per hour
3840 pieces per 8 hours
HR2-10 brick machine production clay bricks requirements for raw materials
The raw materials of HR2-10 brick machine mainly include clay, cement and water. The first is clay, which accounts for 80% of the raw materials. Red soil is recommended for clay. Red soil contains 25%-35% sticky particles, which is more conducive to the molding of clay bricks. The clay raw materials need to be crushed and screened to remove small stones, tree roots and other debris. Among the raw materials for HR2-10 brick machine to produce clay bricks, cement accounts for 10%. Cement is required to be of high quality, not damp, and mixed evenly with clay. Finally, water accounts for 10% of the raw materials in the process of HR2-10 brick machine producing clay. The water quality is required to be clean, free of impurities, and neutral in pH value.
Some photos of customer visits and shipments of HR2-10 brick machine
What equipment is needed for a complete HR2-10 brick machine production line? (5)
Overall size 1500*800*1500mm Max.feeding size 300*400mm Power 5.5kw Capacity 7-10 ton Total weight 320kgs
Power 0.75kw Capacity 7-10 ton Hole diameter 4mm Total weight 350kgs Dimension 1500*800*1200mm
Weight 150kgs Size 4500*700*400mm Motor power 1.5kw Belt type “V”type Speed 1.5m/second
Mixing Motor Power 5.5kw Production Capacity 16m³/h Feed Capacity 350L Efficiency ≥15m³/h Rotating Speed Of Stirring Blade 35r/min Maximum Particle Size Of Bone Particles 8mm/6mm Reducer Model 315
Size 2400*1000*1300mm Power 2.2KW Voltage 12V*4pcs Working hours 10 hours Operation Electro hydraulic Advantage Strong climbing ability、One button lifting、High stability
After the clay bricks are demoulded by the HR2-10 brick machine, workers need to carefully move the clay bricks to the curing area. The curing area should be in a cool and ventilated place, away from direct sunlight, to prevent the moisture in the clay bricks from being lost too quickly and causing cracking. Workers need to sprinkle water on the clay bricks produced by the HR2-10 brick machine 1-2 times a day to keep the surface of the clay bricks moist. If the local climate is abnormally dry, the number of sprinkling can be appropriately increased. After 2-3 days of curing, the clay bricks produced by the HR2-10 brick machine are cured.
The answer is no. One HR2-10 brick machine can produce a variety of brick types, just by changing different molds. HENRY will provide customers with a set of free molds, and customers can also add molds to meet local market demand. HENRY recommends that one HR2-10 brick machine can be equipped with 4-6 molds, mainly promoting local popular brick types to avoid wasting costs.
According to the different uses of clay bricks, the common clay bricks produced by HR2-10 brick machine include 300*150*100mm large two-hole clay bricks, 300*150*100mm U-shaped bricks, 300*150*100mm CLC bricks, and 230*220*115mm hydraform bricks. According to the actual needs of building houses, HENRY engineers designed 150*150*100mm half bricks and 300*150*100mm large two-hole clay bricks with square holes in the middle, etc. Of course, if customers have special brick types, HENRY can also customize them according to customer needs to meet any needs of customers.
The answer is very strong. The strength of clay bricks produced by HR2-10 brick machine depends on the raw material ratio, the pressure of the brick making machine and the maintenance of the clay bricks. As long as the raw material ratio and scientific maintenance are provided by HENRY, the 40 tons pressure provided by HR2-10 brick machine can fully press the clay raw materials very tightly, the strength can reach 10-15 MPa, and the service life can be as long as 30-50 years.
