The xcmg wheel loader is a standard wheeled loader designed for general-purpose applications, such as construction sites and sand and gravel yards.
The xcmg wheel loader delivers powerful, reliable performance and robust working capability. Equipped with an electronically controlled high-pressure common-rail engine producing 92 kW of power, it offers ample output and high fuel efficiency. Operators can switch between light-load and heavy-load modes based on the task at hand, maximizing energy savings and ensuring excellent cost-efficiency. As a 3-ton wheel loader, the XCMG machine features a configuration suitable for a wide range of applications, making it highly popular among customers.
The xcmg wheel loader is equipped with a fixed-shaft transmission and drive axles featuring high overload capacity, making it fully capable of handling heavy-duty operations. Its 1.6 m³ bucket offers low penetration resistance and high capacity, ensuring excellent fill and load retention rates. Additionally, the xcmg backhoe loader features a high-displacement hydraulic system that delivers powerful performance and rapid operation, including fast material unloading. With a rated load of 3,000 kg, a dumping height of 3,200 mm, and a maximum breakout force of 86 kN, the loader ensures high operational efficiency.
The xcmg wheel loader measures 6,740 x 2,460 x 3,020 mm and weighs 8,500 kg. It features top-tier components—including the engine, hydraulic pumps, cylinders, and valves—sourced from renowned brands, ensuring excellent quality, durability, and robust construction. Its high-performance core configuration has been validated by the real-world experiences of numerous customers. Built with high-quality materials, the xcmg wheel loader boasts a sturdy frame and thick steel plating; it maintains normal operating temperatures even during five hours of continuous operation. On international machinery websites, the model has earned a quality score of 95, demonstrating the high regard in which users hold this equipment. In summary, as a leading brand in the industry, the xcmg wheel loader holds distinct advantages in areas such as manufacturing, the selection of core components, processing techniques, and after-sales service.
The xcmg wheel loader is equipped with a 92 KW diesel engine.
As the best-selling model in the 3-ton class, the xcmg wheel loader is equipped with a 92 kW engine from a renowned domestic brand. It features an electronically controlled high-pressure common-rail system, offering high torque reserve and powerful performance, while also delivering excellent fuel efficiency and energy savings. The xcmg india loader allows operators to switch between light-load, medium-load, and heavy-load modes based on the intensity of the task, ensuring operational efficiency while minimizing fuel consumption.
The xcmg wheel loader features a high-displacement hydraulic system.
The xcmg wheel loader is equipped with a high-displacement, single-pump flow-splitting hydraulic system that delivers robust hydraulic power, exceptional force, and impressive lifting speeds. With a maximum breakout force of 86 kN, the loader operates with greater power and smoothness throughout the entire loading cycle—from penetrating the material pile to lifting and unloading. In addition to its powerful hydraulic performance, the XCMG Indonesia loader features an international-standard sealing design that ensures a leak-free system, resulting in enhanced safety and reliability.
The xcmg wheel loader is equipped with a fixed-shaft transmission.
The countershaft transmission featured in the XCMG wheel loader is one of XCMG’s core products, backed by extensive technical expertise, R&D capabilities, and established production lines for various transmission models. The transmission equipped on the xcmg grader loader is mature, reliable, and durable. Paired with a three-element torque converter, it ensures optimal power utilization; for customers requiring high-intensity, long-duration operation, the fixed-shaft transmission featured in the liugong wheel loader is crucial.
The xcmg wheel loader is equipped with a large-capacity 1.6 m³ bucket.
The XCMG wheel loader is equipped with a bucket featuring a standard capacity of 1.6 m³ and a rated load of 3,000 kg. Fabricated from high-strength, wear-resistant materials, the bucket ensures durability and resistance to wear during prolonged operation with materials like sand and gravel, resulting in a long service life. Its connection to the frame is secure, offering a robust, structurally sound, and highly durable assembly. The XCMG UK loader is equipped with a bucket designed for easy penetration into material piles and a high fill factor; combined with a high-displacement hydraulic system, it delivers rapid loading speeds and high operational efficiency, while a wide range of optional attachments ensures versatility across diverse applications.
The xcmg wheel loader are ideally suited for applications such as transportation infrastructure construction, municipal sanitation, sand and gravel yards, brick and tile plants, ports, and farms.
We also offer other popular construction machinery and construction equipment for you to choose from
The xcmg wheel loader technical parameters and real picture display
- Technology datas
- picture of a The xcmg wheel loader
| Type | Front Loader |
| Engine Brand | Famous brand |
| Power(W) | 92 KW |
| Warranty | 1 Year |
| Machine Weight | 8500kg |
| Hydraulic Pump Brand | Famous brand |
| Brand Name | Famous brand |
| Bucket capacity | 1.6 m³ |
| Power Type | Diesel |
| Moving Type | Wheel Loader |
| Dimension(Long * Breadth * High) | 6740*2460*3020 mm |
| Machinery Test Report | Provided |
| Video outgoing inspection | Provided |
| Product name | XCMG wheel loader |
| Bucket Load | 1.6 m³ |
| Operating Weight | 8500 kg |
| Load capacity | 3000 kg |
| Unloading height | 3200 mm |
| Max. breakout force | 86 kN |
Get More Operation Videos
How to operate a xcmg wheel loader correctly and according to standard procedures
1. First, it is necessary to check the XCMG wheel loader’s tire pressure, fuel level, and the hydraulic system for leaks.
2. Next, the operator starts the XCMG wheel loader price’s engine and lets it warm up at idle for 3 to 5 minutes; then, they raise the bucket to a height of 50–60 cm, shift into a low gear, gently press the accelerator, and move off smoothly.
3. The operator drives the XCMG wheel loader LW500FN to the front of the material pile, inserts the bucket straight into the pile, and fills the bucket with material by operating the lift and tilt control levers.
4. After filling the XCMG LW300FN loader’s bucket with material, the operator slowly lifts and tilts the bucket forward to discharge the contents into the transport vehicle.
5. After loading is complete, the operator drives the LW500FN XCMG wheel loader to the parking area, lowers the bucket flat onto the ground, engages the parking brake, and turns off the engine; the operator then exits the cab and locks the doors.
First, this XCMG wheel loader is ideally suited for transportation infrastructure and urban construction projects, offering high efficiency in tasks such as loading and unloading sand, gravel, and aggregates, as well as handling earthwork backfilling and material transfer. It easily tackles the rigorous demands of highway, bridge, and residential community construction thanks to its exceptional power and hydraulic capabilities. Next are sand and gravel yards; whether handling sand, crushed stone, or mineral resources, the XCMG paver loader performs rapid loading and unloading operations with its large 1.6 m³ bucket. Furthermore, it is equipped with a high-displacement hydraulic system that ensures high operational efficiency. Finally, the XCMG ZL50GV loader excels in logistics and storage applications—particularly at grain depots, feed mills, and livestock farms—where it easily manages the loading, unloading, and transfer of materials.
The xcmg wheel loader’s status as a best-selling model is inseparable from its core configuration—comprising the powertrain, hydraulic system, and drivetrain—which is known as the XCMG machine’s “golden combination.”
First is the powertrain: the XCMG wheel loader utilizes an electronically controlled, high-pressure common-rail engine delivering 92 kW of robust power, featuring three operating modes—light, medium, and heavy load. Next is the hydraulic system: the XCMG wheel loader LW300FN is equipped with a high-displacement, single-pump split-flow hydraulic system that offers excellent sealing and a maximum breakout force of 86 kN. Finally, there is the drivetrain: it features a fixed-shaft transmission paired with drive axles, ensuring high overload resistance.
When operating the XCMG wheel loader, the driver should start in a low gear and drive at a steady, uniform speed; the bucket must not be raised, lowered, or tilted while the machine is in motion. When using a XCMG wheel loader lw500fn for scooping and loading, keep the bucket level and insert its front face straight into the material pile; avoid overloading, as well as abrupt maneuvers or sharp turns. When parking the XCMG wheel loader 5 ton, the bucket must be lowered to the ground, the machine parked on level ground, and the parking brake engaged.
First, prioritize lubrication and maintenance: the XCMG wheel loader’s joints require regular greasing to ensure smooth operation, minimize wear, and extend service life; the drive shaft and chassis connection points also need periodic lubrication. Additionally, regularly monitor the condition of the air filter and clean or replace it as needed. Finally, before starting work each day, check that fuel, engine oil, and coolant levels are sufficient, and regularly replace the engine, transmission, and hydraulic tank filter elements.
A major advantage of the xcmg wheel loader is its high efficiency and energy-saving capability; it utilizes an electronically controlled high-pressure common-rail engine that precisely regulates fuel injection for superior combustion efficiency, while offering three operating modes—light, medium, and heavy load—to maximize fuel savings.
This XCMG wheel loader features a spacious cab with a panoramic rear window, providing the operator with excellent visibility and thereby enhancing operational safety. Furthermore, the cab incorporates automotive-grade appointments—such as comfortable seating, refined interior trim, and rubber flooring—creating a roomy and comfortable environment while ensuring a clear view of the surroundings.
