Henry hot sale semi-automatic QT40-1 block maker machine
1.QT40-1 block maker machine is a semi-automatic concrete brick-making machine sold very well by HENRY Company. It is deeply loved by customers in Africa and America because of its simple operation, low price and large output.
2.QT40-1 block maker machine has a hopper design, and concrete raw materials can be transported to the hopper at the top of QT40-1 by conveyor belt, which is very convenient for feeding.
3.This QT40-1 block maker machine has a size of 1500*1600*2300mm and a weight of 1600kgs. It has a power of 8.8kw and a vibration force of 30kn, which makes the produced concrete bricks compact, compact and firm.
4.QT40-1 block maker machine has a large output. Five concrete bricks of 400*150*200mm can be formed every 40s, and 4,100 concrete blocks can be produced in 8 hours. Support the replacement of block maker molds, and can produce different sizes of concrete hollow blocks, concrete solid bricks, cement bricks, interlock pavement bricks ,curbs and other brick types.
5.QT40-1 block maker machine PLC electric control box with touch buttons, vibration motor,lifting motor,mold-feeding motors, and other electrical components are all domestic brands and imported electronic parts from Germany as Siemens, ABB, Schneider and so on.
What supporting equipment does QT40-1 block maker machine need?
1.PLC electric control box(It has the controlling unit button for operator to press to control each process)
2.JQ350 concrete mixer(It is designed with gear box reducer 350 model,and 7.5kw powerful motor, and 10mm thickness of steel plate)
3.6m long conveyor belt(It has 8mm thick Imported rubber belt, with wear-resistant steel wire inside, can withstand the mo sun of large particles of sand and gravel)
What convenience can the hopper design of QT40-1 block maker machine bring?
The concrete raw materials stirred by JQ350 mixer are transported to the hopper of QT40-1 block maker machine through the 6m-long conveyor belt. Workers can automatically drop the raw materials into the mold by pulling down the operating lever, which is very simple and convenient for saving labor.
What important role can vibrator play in QT40-1 block maker machine?
The three kilowatter vibrator of QT40-1 block maker machine distributes the concrete raw materials in the mold quickly and evenly through high-frequency vibration, preventing the accumulation of concrete raw materials, making the concrete bricks more compact and the surface smoother.The vibration motors are all wound with pure copper cores, which have faster speeds than motors with aluminum cores, are less prone to overheating, and extend the life of the vibrator.
Can customers customize the color of QT40-1 block maker machine according to their favorite color?
Of course, customers can choose their own colors. Customers can choose their favorite colors or colors consistent with their brand image to enhance the unity of their brands. Customers need to pay attention, and the customized color needs to be explained to HENRY company in advance. Once painting QT40-1 block maker machine is completed, it cannot be changed.
QT40-1 block maker machine is the most popular semi-automatic concrete brick-making machine in Tanzania, Ghana, Nigeria and other African countries.
We also have manual concrete block maker machine, semi automatic block maker machine, movable egg layer block maker machine, stability block maker machine, hollow block maker machine, mobile concrete brick making machine ,fly ash brick maker machine, cinder block maker machine, cement paving brick machine and automatic concrete brick making machine for you to choose from.
QT40-1 block maker machine technical parameters and capacity
- Technology datas
- QT40-1 block maker machine production output
| Overall Size | 1500*1600*2300mm |
| Vibration Force | 30kn |
| Mould Period | 40s |
| Host Machine Power | 8.8kw |
| Host Machine Weight | 1.6T |
| Production Capacity | 2400-3600PCS/Day |
| Workers | 2-3 workers |
| Block mould | One set for free |
| Warranty of core components | 1 year |
| Color | Can be customized |
| Machinery Test Report | Provided |
Get More Operation Videos
HENRY Company teaches you how to operate this QT40-1 block maker machine correctly.
1.Please ensure that QT40-1 block maker machine, conveyor belt, and mixer are connected to a suitable and stable power source. if your order is 380 voltage / 50hz, three phase, then you must guarantee your cable voltage are the same. if not, then wires are easily to be burned.
2.Prepare the raw materials required for producing blocks, such as sand, cement, aggregates, water, etc.
3.First, turn on the mixer and let it work.Make sure to switch on the mixer first, and then add the raw materials in sequence.(if you added material in advance, then mixing motor is easily to be burned),Add water in small amounts multiple times and mix with a mixer for 3-5 minutes.When the raw materials are mixed until the raw material tightly grasped by hand and can agglomerated into blocks, it indicates that the raw materials have been well mixed. if your concrete material is too wet , then your cement bricks are easily to be stuck onto molds.
4.Operate the handle of the mixer to open the mixer, and the raw materials will be transported to the hopper of QT40-1 block maker machine through the conveyor belt.
5.Now you can start making blocks.
a.Rise the mould box, so you can place the pallet on the vibration platform of QT40-1 block maker machine. Please make sure the pallet is in the correct position.
b.Drop the mould box onto the pallet, then shake the handle next to QT40-1 block maker machine hopper to release the raw materials into the mould box.
c.The down mould box vibrates to make the distribution of raw materials more uniform. If the amount of raw materials in the block trough varies,you can use the rake we give away to push the raw materials more evenly and vibrating the down mould box again.
d.Pull the upper mould forward and fall into the mould box, and the up and down vibration motors vibrate together.Vibration for about 10 seconds.The vibration time can be increased or decreased based on the performance of the produced blocks and the conditions of the raw materials.
e.Raise the mould box, and the block you made will appear in front of you.You can use the barrow we provide to transfer the newly produced fresh blocks to the curing area.
f.The climate, temperature, humidity, and duration of light vary from country to country.The specific curing time depends on local climate .
g.During the process of drying blocks, it is necessary to regularly spray water on the blocks to solidify the cement and make them more solid.
This semi-automatic block maker machine weighs 16000kgs. Henry block machine manufaturer uses two 2.2kw lower vibrators and one 2.2kw upper vibrator. When the upper and lower vibrators are turned on at the same time, it can generally produce a vibration force of 40kn. For the production of conventional hollow blocks, solid bricks, and pavement interlocking bricks, the pressure is very good. Two adults can stand at the same time to test the firmness of the fresh bricks.
In response to the market demand for local bricks, most builders will choose hollow blocks or solid bricks and pavement bricks of different sizes. Therefore, when customers purchase block maker machines, they all require the production of different types of bricks. for example, hollow blocks, solid bricks, cinder blocks, fly ash bricks, color pavers, pavement interlocking bricks, Our Henry block maker machines are multifunctional and multi-purpose equipment, which means that different bricks can be produced by replacing different molds. However, the mold cost is relatively high. Because our molds are made of the hardest steel plate Q345 manganese steel, carburizing technology and heat treatment technology, the mold price will inevitably be higher. The way we help customers reduce mold costs is to put bricks of different sizes into one mold, that is, a mixed combined mold, so that the amount of mold investment can be reduced.
Because the price of ocean freight often fluctuates, we sincerely hope to help Henry’s users reduce their ocean freight expenses, so we will try our best to reduce the packaging volume. Generally, the main brick machine is four cubic meters, the conveyor belt is 0.5 cubic meters, and the mixer is one cubic meter, a total of six cubic meters.
